Create node and categories in one REST call

Anyone know what the syntax is to create a new node AND a couple of categories/attributtes via the POST api/v2/nodes REST call? The implementation notes say to see the implementation notes on how, but I must be looking on the wrong implementation notes, as I'm not seeing it.

Image: https://us.v-cdn.net/6030023/uploads/editor/cd/gwbxh13dgokq.png

Find more posts tagged with

Comments

sıɹɥɔ

https://knowledge.opentext.com/go/67789539 may be what you're looking for

Peter Kulig

Got the answer from support, if anyone needs it:
In addition to the file form value, the call needs a 'body' form value in the following format:

{

"name":"test",

"parent_id":123,

"type":144,

"roles":{

"categories":

{

"12345_2":"12345"

}

Alex_dacore

Hi Peter,

can you give me a hint how to use the 'body' form value? I am a VB6 developer and upload a file successfully, but now I have to fill some categories. I don't know the difference between 'file form values ' and 'body form values'.

If I use

sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""body""" & vbCrLf & vbCrLf & "{""name"":""22-0058-D02_1a.pdf"",""parent_id"":15362328,""type"":144,""roles"":{""categories"":{""_1_1_2_1"":""12345""}}}" & vbCrLf

I get the Error: 400 Bad Request {"error":"Der Textparameter ist ung\u00fcltig.","errorDetail":"Es besteht ein Konflikt zwischen den Text- und Formularparametern."}

This is my code:

' post

120 Set xmlHttp = CreateObject("Microsoft.XMLHTTP")

130 With xmlHttp

140 .Open "POST", v_strUrl, v_blnAsync

141 .SetRequestHeader "OTCSTicket", v_strOTCSTicket

150 .SetRequestHeader "Content-Type", "multipart/form-data"

160 .SetRequestHeader "cache-control", "no-cache"

170

180 .SetRequestHeader "content-type", "multipart/form-data; boundary=" & STR_BOUNDARY

190 sPostData = "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""type""" & vbCrLf & vbCrLf & "144" & vbCrLf

200 sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""parent_id""" & vbCrLf & vbCrLf & v_strParentId & vbCrLf '"11161128" "79497"

210 sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""file""; filename=""" & GetFileName(v_strFilename) & """" & vbCrLf & "Content-Type: " & GetMimeType(v_strFilename) & vbCrLf & vbCrLf & sPostData2 & vbCrLf ' "Content-Type: text/plain"

220 sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""name""" & vbCrLf & vbCrLf & v_strName & vbCrLf

'sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""description""" & vbCrLf & vbCrLf & "beschreibung" & vbCrLf

'sPostData = sPostData & "--" & STR_BOUNDARY & vbCrLf & "Content-Disposition: form-data; name=""Documenttype""" & vbCrLf & vbCrLf & "DasIstDerDocumentType" & vbCrLf

230 sPostData = sPostData & "--" & STR_BOUNDARY & "--"

'WriteToLogFile "multipart", sPostData

240 .Send pvToByteArray(sPostData)

Appu Nair

I believe you are very close and perhaps may not understand what the fake body parametrizing is.In my blog there is ome information and screencaps shown in POSTman

https://appukili.wordpress.com/2022/04/17/take-some-rest/

this JSON string is probably wrong

""roles"":{""categories"":{""_1_1_2_1"":""12345""}}}

I woulld expect that a Cataegory Object in CS is identified by a DataID and its version

if you look at the JS code

var form = new FormData();

form.append("file", fileInput.files[0], "/C:/Windows/Temp/helloworld.txt");

form.append("body", "{

\"type\": 144,

\"parent_id\": 2000,

\"name\": \"apooppa\",

\"roles\": {

\"categories\": {

\"22783\": {

\"22783_2\": \"bbb\"

}

}");

In this I am constructing a payload saying 22783 is my Category and 22783_2 is my leaf or attribute

If you are a starter in CS if you run the command ?func=attributes.dump OT will show you a listing based on Attributes and Types.

one or two more screen cap kind of links

URLBOTTOFAKEhttps://forums.opentext.com/forums/developer/discussion/comment/950787#Comment_950787

https://forums.opentext.com/forums/developer/discussion/comment/948156#Comment_948156

I use Postman where you can understand the different parts of a HTML form submission, what OT means is inside form data you need to construct name/value pairs as the CS application is not fully a JSON app.

Alex_dacore

Thank you Appu Nair for your advice. I already found out, that the Category has the ID 15389062 (with the .../otcs/llisapi.dll?func=attributes.dump):

But I don't know, if the attribute has the ID 2 or if it has the ID 15389062_1_1_7_1 , like the input box hat the htmlcode: <input class="valueEditable" type="text" name="_1_1_2_1" title="Documenttype" id="_1_1_7_1" value="" size="50" maxlength="254" onchange="markDirty();">

If I made some changes, to look like yours, it doesn't works:

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Type: text/plain; charset=utf-8

Content-Disposition: form-data; name="body"

{"name":"22-0058 abc.pdf","parent_id":"15362328","type":144,"roles":{"categories":{"15389062_1_1_7_1":"12345"}}}

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113--

I get the error {"error":"Der Textparameter ist ung\u00fcltig.","errorDetail":"Es besteht ein Konflikt zwischen den Text- und Formularparametern."} There is a conflict between the text and form parameters.

400 Bad Request 400 {"error":"Der Textparameter ist ung\u00fcltig.","errorDetail":"Der Parametertext kann nicht in Assoc oder eine Liste von Assocs umgewandelt werden."} The parameter text cannot be converted to assoc or a list of assocs.

Is the Assocs error a common web service error or an openText specific error?

If I use {"name":"22-0058 abc.pdf","parent_id":"15362328","type":144,"roles":{"categories":{"15389062_2":"12345"}}}

I get the error: "There is a conflict between the text and form parameters."

I think that the webservice doesn't recognize the json object, because if I use no line breaks and use the following

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="body"

{"name":"22-0058 abc.pdf","parent_id":"15362328","type":144,"roles":{"categories":{"15389062_1_1_7_1":""}}}--3fbd04f5-b1ed-4060-99b9-fca7ff59c113--

I get the same error, like I put an empty string into the body: Bad Request 400 {"error":"Der Textparameter ist ung\u00fcltig.","errorDetail":"Bei dem Text muss es sich um eine nicht leere Zeichenfolge handeln."}/The text must be a non-empty string.

How can I tell the webservice, that the string at the form-data field "body" is an json object? This is my RequestHeader:

SetRequestHeader "content-type", "multipart/form-data; boundary=3fbd04f5-b1ed-4060-99b9-fca7ff59c113"

Thx in advance.

Alex

Appu Nair

if you want to send an attribute for the Attribute called Number one would say 15389062_3

you will also need to in your payload(please download postman and send the payload using that)

\"roles\": {

\"categories\": {

\"15389062\": {

\"15389062_3\": \"1\"

Alex_dacore

Hi Appu Nair,

thx for your response. But what should help me postman, if I don't know how to create/send the json? I will get the same error, like I do, if it send it with my VB6 application... This doesn't help me.

I can put

{"name":"Textdatei.txt","parent_id":"15362328","type":144,"roles":{"categories":{"15389062_3":"12345"}}}

or your code into the body:

{\"name\":\"Textdatei.txt\",\"parent_id\":\"15362328\",\"type\":144,\"roles\":{\"categories\": {\"15389062\": {\"15389062_3\": \"1\"}}}}

but I get the same error "Parameter body can not be converted into Assoc or a list of Assoc"

For me is postman completly useless. I dont' know the sense of postman, but this is another topic ;-)

Appu Nair

JSON STRING SNIPPET using JSON LINT https://jsonlint.com/

Create document Called MY Document at 49593 and Apply Category 52998 with Value aaa

Postman Pay Load

Code in HTTP

POST /otcs/cs.exe/api/v1/nodes HTTP/1.1
Host: ****.,,,,,.com
otdsticket: *OTDSSSO*AA
Cache-Control: no-cache
Postman-Token: 59af2654-24c4-c615-d272-b6f7c15ca6cc
Content-Type: multipart/form-data; boundary=----WebKitFormBoundary7MA4YWxkTrZu0gW

------WebKitFormBoundary7MA4YWxkTrZu0gW
Content-Disposition: form-data; name="file"; filename="appu_phone_bill_aug2022.pdf"
Content-Type: application/pdf


------WebKitFormBoundary7MA4YWxkTrZu0gW
Content-Disposition: form-data; name="body"

{
	"type": 144,
	"parent_id": 49593,
	"name": "MY Document",
	"roles": {
		"categories": {
			"52998": {
				"52998_2": ["aaa"]
			}
		}
	}
}
------WebKitFormBoundary7MA4YWxkTrZu0gW--

other Coding languages suggested by Postman

Alex_dacore

Thank you Appu Nair, but I did this already in the past. I have done this again exactly like you and gettting the old error: 400 Bad Request 400 {"error":"Der Textparameter ist ung\u00fcltig.","errorDetail":"Es besteht ein Konflikt zwischen den Text- und Formularparametern."}

This ist my message:

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="type"

144

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="parent_id"

15362328

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="file"; filename="Textdatei.txt"

Content-Type: text/plain

Das ist der Inhalt der Textdatei.

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="name"

22-0058-D04_1.pdf

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113

Content-Disposition: form-data; name="body"

{

"name":"Textdatei.txt",

"parent_id":"15362328",

"type":144,

"roles":{

"categories": {

"15389062": {

"15389062_2":["123456"]

}

--3fbd04f5-b1ed-4060-99b9-fca7ff59c113--

In the meantime I found some posts, that OpenText couldn't use JSON: "Only the URL-encoded form and the multipart MIME formats are recognized. JSON is "just a garbage" for the current implementation :-)“

(Source: REST API and JSON — OpenText - Forums )

Alex_dacore

I see that you are using "POST /otcs/cs.exe/api/v1/nodes HTTP/1.1" . I am using "/otcs/llisapi.dll/api/v2/nodes". What is the difference between cs.exe and llisapi.dll?

Alex_dacore

I found more an more hints, that open text can't work with JSON objects. So I tried first to upload the file with a post request and "multipart/form-data" and after that I update several attributes with a PUT request. This works. So all the ID I have used are correct. I don't know why in every official documentation stands "use JSON blabla" but open text doesn't compatible with it. This helped me: Example of PUT REST Request to update category attributes — OpenText - Forums

This is my Visual Basic 6 code which is working:

Set xmlHttp = CreateObject("Microsoft.XMLHTTP")

' Über http://ContentServerName/otcs/llisapi.dll?func=attributes.dump ermittelt man die ID's der Attribute

' ' Attribut ID Typ

' ' Documenttype 2 -1 varchar(255)

' ' Number 3 -1

' ' Version 4 -1

' ' Title 5 -1

' ' Status 6 -1

' ' username Creator 7 -1

' ' username Releaser 8 -1

' ' Created at 9 -7 DateTime

' ' released at 12 -7

' ' Documentident 13 2 Integer

' strNodeID = "15399848"

' strCategoryID = "15389062"

' strAttributeID = 2

xmlHttp.Open "PUT", "http://ContentServerName/llisapi.dll/api/v1/nodes/" & strNodeID & "/categories/" & strCategoryID & "?" & strCategoryID & "_" & strAttributeID & "=123abc&15389062_3=456789", v_blnAsync

xmlHttp.SetRequestHeader "OTCSTicket", v_strOTCSTicket

xmlHttp.SetRequestHeader "content-type", "application/x-www-form-urlencoded"

xmlHttp.Send

Appu Nair

in V2 Version of Code your payload will look like this

{

"type": 144,

"parent_id": 49593,

"name": "MY Document",

"roles": {

"categories": {

"52998_2": ["aaa"]

}

You can see I switched my call to v2 version and llisapi.dll

documentation looks erroneous with the escape sequences a jsonlint did not validate that as JSON

in V2 you can fine tune the Request/Reponse as such in v1 I just get the DataID of the new document ,in V2 I get a lot more as in my screencap .llisapi.dll, cs.exe, cs all of these are cgi scripts for CS.llisapi.dll is a faster implementation of the cs.exe but works only in IIS deployments. As such for the RESTApi they are not relevant

Swapnil Dandagvhal

Opentext has uglist documentation and REST APIS i am facing same issue
